Short Compressor Kit

Specs

Specifications

• KIT: COMPRESSORS: 204-14241
• KIT: ACCUMULATORS/DRIERS: 207-5016
• KIT: EXP VALVES/ORIF TUBE: 208-291-1
• {EXP VALVES/ORIF TUBE}: Screen Micron Rating: 100 mesh
• {EXP VALVES/ORIF TUBE}: Length (mm): 102
• {COMPRESSORS}: Voltage: 12
• {COMPRESSORS}: Pulley Diameter (mm): 124
• {COMPRESSORS}: Discharge Port (mm): 15
• {ACCUMULATORS/DRIERS}: Length (mm): 205
• {ACCUMULATORS/DRIERS}: Inlet/ Outlet (mm): 21
• {COMPRESSORS}: Suction Port (mm): 28.4
• {COMPRESSORS}: Grooves: 6
• {EXP VALVES/ORIF TUBE}: Inner Diameter (mm): 6.2
• {COMPRESSORS}: Gauge Line (mm): 60
• {ACCUMULATORS/DRIERS}: Diameter (mm): 75
• {COMPRESSORS}: Compressor Type: 7SEU17C
• {EXP VALVES/ORIF TUBE}: Diameter (mm): 9.8
• {EXP VALVES/ORIF TUBE}: Tube Outside Diameter: 9.8
• {EXP VALVES/ORIF TUBE}: Color: Black
• {COMPRESSORS}: Compressor Mount: Boss
• {COMPRESSORS}: Rotation: CW
• {ACCUMULATORS/DRIERS}: Sight Glass (Y/ N): N
• {EXP VALVES/ORIF TUBE}: Material Type: Plastic
• {COMPRESSORS}: Control Valve (Y/ N): Y
