Description
2-port vacuum solenoid valve
An electrically-operated 2-port vacuum solenoid that switches a vacuum signal on or off to drive vacuum-actuated components — HVAC mode/blend doors, heater (water) control valves, and other A/C and climate-control vacuum functions. A universal replacement that cross-references UAC SW9001C.
Turns an electrical signal into a vacuum action
Many HVAC and A/C controls are vacuum-operated — mode doors that direct airflow, water valves that turn the heater core on and off, and similar actuators. A vacuum solenoid is the electric “switch” in that vacuum circuit.
When the solenoid is energized, it opens or closes the vacuum path between its two ports, applying or venting vacuum to the actuator it controls. That lets an electrical input (a switch, relay, or control head) command a vacuum-driven part.
Know exactly what you're ordering
Reliable electric vacuum switching
Electric vacuum control
Switches a vacuum signal on command, so an electrical input can drive a vacuum actuator.
Two-port design
A simple two-port valve for applying or venting vacuum to a single actuator circuit.
Universal replacement
A versatile solenoid that covers a range of HVAC/A/C vacuum-control applications.
OE interchange
Cross-references UAC SW9001C, Autocomp Technologies, Global Air, and Global Cool Cars.
Compact
Small footprint that mounts easily in tight dash and engine-bay locations.
Simple wiring
Straightforward electrical hookup to a control switch, relay, or climate-control head.
Vacuum-controlled HVAC & A/C
Mode / blend doors
Directs vacuum to the actuators that move HVAC mode and blend doors.
Heater / water valves
Controls vacuum-operated heater (water) control valves.
A/C & climate controls
Other vacuum-actuated A/C and climate-control functions.
Custom & retrofit
A handy universal vacuum switch for custom and retrofit HVAC builds.
Interchange & cross-reference numbers
| Brand | Part number |
|---|---|
| UAC | SW 9001C |
| Autocomp Technologies | 959001 |
| Global Air | SV2000 |
| Global Cool Cars | 4630Z0107 |
Technical details
Wire it up
Connectors & pigtails
Find the connector or pigtail to wire the solenoid into your harness.
Shop connectors →Universal switches
Browse universal switches for the rest of your HVAC/A/C controls.
Shop switches →Vacuum solenoid FAQ
What is a vacuum solenoid?
What does it control?
How many ports does it have?
What voltage is it?
Will it work in my system?
